RADION R9
Rugged Android Tablet for Industrial Use, Field Work, and Secure Data Capture
The Radion R9 is a high-performance, enterprise-grade rugged tablet engineered for use in the most demanding environments. With its powerful processing options, large HD display, extended battery life, and built-in security features, the R9 delivers seamless field operations in logistics, security, construction, mining and transport. Whether deployed in the field, on-site, or in mobile control applications, the R9 provides a reliable platform for data collection, task management, communication, and reporting, all within a tough, IP68-certified enclosure.
Smart ScannerRADION R9
Rugged Android Tablet for Industrial Use, Field Work, and Secure Data Capture
The Radion R9 is a high-performance, enterprise-grade rugged tablet engineered for use in the most demanding environments. With its powerful processing options, large HD display, extended battery life, and built-in security features, the R9 delivers seamless field operations in logistics, security, construction, mining and transport. Whether deployed in the field, on-site, or in mobile control applications, the R9 provides a reliable platform for data collection, task management, communication, and reporting, all within a tough, IP68-certified enclosure.
Smart Scanner
Key Features
Configurable RAM and Storage
Choose between 4GB RAM with 64GB storage or 8GB RAM with 128GB storage to suit application needs—from lightweight workflows to high-performance multitasking in complex environments.
10.1-Inch IPS Full HD Display
The large, high-resolution screen offers clear, vibrant visuals—ideal for mapping, forms, photo documentation, and real-time dashboards, even in bright outdoor conditions.
Dual Camera System for Field Documentation
Equipped with a 13MP rear camera and a 5MP front camera capable of 720p video, the R9 makes incident capture, reporting, and remote conferencing simple and effective.
Integrated 2D Barcode Scanner
Enable fast, accurate scanning for inventory, asset management, access control, and field data collection with the built-in 2D scanner.
Fingerprint Recognition for Secure Access
Keep sensitive apps and data protected with biometric authentication, streamlining secure login for authorized users.
IP68 Waterproof and Dustproof Rating
Built for all-terrain performance, the R9 is fully sealed against dust, dirt, and water— ready for use in warehouses, vehicles, construction sites, and extreme weather.
Massive 10,000mAh Battery for All-Day Use
Power through long shifts with confidence. The high-capacity battery supports extended field use without downtime, even during heavy app usage or continuous connectivity.
Enterprise App Compatibility (Android OS)
Run custom enterprise applications, workflow platforms, PTT communication, tracking systems, and more
-
Operating System
Android 10
-
Hardware Platform
MTK6771
-
Radio Frequency
GSM (B2/3/5/8); WCDMA (B1/2/5/8); TD-SCDMA (B34/39); LTE-FDD (B1/2/3/5/7/8/20); LTE-TDD (B34/38/39/40/41)
-
RAM
4GB + 64GB / 8GB + 128GB (RAM + Storage)
-
Display
8” / 10.1”IPS Screen, QVGA 1280×800 G+G
-
GPS
GPS, GLONASS & AGPS
-
WiFi
802.11 a/b/g/n/ac, dual-band
-
Bluetooth
BT V4.2
-
USB Interface
Micro USB 2.0
-
SIM Card
SIM single card
-
Encoding / Decoding Capabilities
H.264 high profile, 720P 30FPS
-
Sensor
Gyroscope, Compass, Gyroscope, Light, Proximity, NFC
-
Speaker
36mm ⏀ 2.0W @ 90dB
-
Microphone
Sensitivity -42dB
-
Front Camera
13 million pixels camera
-
Rear Camera
16 million pixels camera
-
Video Quality
Support 720P video recording
-
DC Interface
5V/3A
-
POGO Pin
12 Pin
-
Working Environment
Temperature -20 °C - 60 °C, humidity 95% Non-Condensing
-
Degree of Protection
IP68, water & dust resistance, anti-drop 1.2 meters
-
Weight
774g (8”) / 1190g (10.1”)
-
Battery Capacity
10,000mAh
-
Working Hours
≥10h
-
Size
227mm x 142.4mm x 22.5mm (8”)
276mm x 180.5mm x 22.5mm (10.1”)
